Model: TZ-TSMD600
Function : Fixed automatic numbing system,which is used for the electric stunning
Operational principle : This device will fix pig head position firstly to guarantee the best stunning effect. During the process of the operation, 3 electrodes are positioned in the head and the heart. The third electrodes（for heart） will provide a relax current to the pig, which could reduce pig’s spasm and easy for inserting bloodletting bayonet and hanging. Pigs can reduce the stress response, bone defects & congestion, PSE meat,good for meat quality.
The special design of the conveyor can hold the pig's abdomen, so that the pig is suspended, can avoid pig’s secondary damage.
Equipment introduction:
1.The frame adopts 80 x 40 x 4, 140 x 80 x 4mm stainless steel rectangular tube production.
2.Both sides of the aisle shield made of 40 x 20 x 2 stainless steel pipe and plate is made of 12mm thick high quality nylon plate; the side frame of the conveyor, head cover adopts a 12mm thickness high quality nylon plate. Power shield, on both sides of the shield are made of 1.5mm thick stainless steel plate.
3.The abdominal part adopts special rubber plate making
4.The chain(pitch 100mm), sprocket, transmission shaft, are made of stainless steel
5.Including shower nozzle and valve
6.The selection of pneumatic components are FESTO" brand.
7. PLC program control system, transportation system, the main electrical components such as PLC, photoelectric switch, an intermediate relay are well-known brand products, low-voltage electrical by well-known chinese domestic brands.
8.Stunning power use our indigenous low voltage and high frequency,head electric power is 2KVA; heart electric power: 1KVA
9.Reducer is famous brand in China ---"Tongyu", motor power 2.2KW, protection grade IP55.
10.The production capacity: no more than 600 head / hour
11. Pig escape rate is less than or equal to 3%
12.The pig body “3- fault rate” less than 5%
